Specs
| Adjustable Discharge Baffle | Fill Reduction Baffles Standard |
|---|---|
| Air Filter | Heavy-Duty Canister Air Cleaner |
| Blade Tip Speed | 18,500 ft/min / 5,638 m/min |
| Blades | 0.164 in. (0.417 cm) heat-treated steel |
| Box Dimensions | 91 in. x 70.25 in. x 52.25 in. / 231.1 cm x 178.4 cm x 132.7 cm |
| CARB Compliant | CARB Compliant |
| Carrier Frame | 2 in. x 1.5 in. x 11 gauge (5.1 cm x 3.8 cm x 11 gauge) |
| Caster Tires | 8 in. x 3 in. - 4 in. (20.3 cm x 7.6 cm - 10.2 cm) Semi Pneumatic |
| Clutch | Mechanical (lever-operated) |
| Deck Design | 7/10 gauge |
| Deck Material | 7/10 Gauge Steel |
| Deck Size | 48 in / 122 cm |
| Drive System | Tandem Pumps and Wheel Motors |
| Drive Tires | 18 in. x 10.5 in. - 10 in. (45.7 cm x 26.7 cm - 25.4 cm) |
| Engine | 23 hp* (17.1kW) Kohler® Command Pro EFI 747 cc |
| Engine Brand | Kohler |
| Engine Displacement (cc) | 747 cc |
| Engine Horsepower | 23.0 hp |
| Forward Ground/Transport Speed | Up to 7.0 mph / 11.2 kph |
| Fuel Capacity | 7.5 gal. / 28.4 L / 30 Qt. |
| Fuel Type | Gasoline |
| Height of Cut | 1.0 - 4.0 in. / 2.5 - 10.2 cm |
| Hour Meter | Standard Hour Meter |
| Product Type | Zero Turn Mowers |
| Product Use | Commercial |
| Seat | Rubber Mounted |
| Spindle Housing | Cast Iron Gearbox |
| Start Type | Electric |
| Steering Controls | Hand Control Levers |
